You’ll want to be seen in the Mixx
An active or semi-active wheelchair user wants a foldable chair with excellent riding capabilities, where sitting comfortably goes without saying. The Mixx, with its seat comfort that can be further personalised with the Matrixx seating system, offers the total package. With a design that does away with all preconceptions about wheelchairs.

  • Low lifting weight
  • Easy to fold and take with you
  • Adjustable wheel base
  • High level of sitting comfort
  • Crash test-safe
Product images
Specifications
Abbr. Measurement points Specifications
SW Seat width 37 / 42 / 47 / 52 cm
SD Seat depth
icw straps, seat mat and cushion* 42 - 52 cm
icw Matrixx standard seating & backrest** 42 - 52 cm
SH Seat height
icw straps, seat mat and cushion 45 - 55 cm
icw Matrixx standard seating & backrest** 42 - 58 cm
BH Back height Adjustable by cm
AH Armrest height
icw straps, seat mat and cushion 16 - 24 cm (13 positions)
icw Matrixx standard seating & backrest 15 - 23 cm (13 positions)
WW Wheelchair width SW + 24 cm
folded (incl. wheels) 28 cm
WL Wheelchair length 100 / 105 / 110 cm
LL Lower leg length
icw straps, seat mat and cushion 38 - 48 cm
icw Matrixx standard seating & backrest 41 - 51 cm
Seat angle 3º or adjustable
Backrest angle adjustment 17.5 kg
Lifting weight 8 kg
Maximum user weight 140 kg
Complies with EN 12182, EN 12183, ISO 7176-19
Crash test safe yes

* Seat depth is measured from front of seat to back tube

** Seat height and seat depth are measured with the Matrixx measurement sheet for other configurations

afmetingen
Characteristics

The Mixx in brief

  • Extensive seat support with the Matrixx seating system
  • Modern/distinctive design
  • Low lifting weight
  • Easy to fold and take with you
  • Standard with pedal bar and handles that can be adjusted in height
  • Adjustable wheel base
  • High level of sitting comfort
  • Adjustable seat depth, seat height, seat angle and back angle
  • Matrixx seating parts can be switched with other Life & Mobility chairs
  • Quick-release rear wheels
  • Various options and accessories such as headrest, table top, cane holder, spoke protectors, posture belt
  • Crash test-safe; approved for transport in taxi or minibus
