Morgan

In control with the Morgan
Individual Matrixx seating system seat support combined with comfort and manoeuvrability. High seat elevation means you always have the right seat height. Easy to adjust seat angle, back angle and seat height. The Morgan has a small turning radius and an independent wheel suspension system.

  • Customised seat support
  • Customised controls
  • Comfortable and safe on the road
  • Stability and safety guaranteed
  • Easy to maintain and reusable
  • Unity of frame and seat support
Product images
Specifications
Abbreviation Measurement points Specifications
SW Seat width 37 - 57 cm
SD Seat depth 42 - 56 cm
SH Min. seat height (including cushion) 52 - 82 cm
TH Total height 109 cm
TL Total length 94 cm (incl. leg rests)
TW Total width 60 cm
Seat angle reach 0 - 50°
Back angle reach 85 - 160°
Maximum speed 6, 10 and 12.5 km/h
Action radius 25 km
Batteries 2x50 Ah
Charger 6A/24V, 8A/24V
Total weight (incl. batteries) 105 kg
Maximum user weight 136 kg
Turning radius 64 cm (82 incl. leg rests)
Front wheels diameter 8”
Rear wheels diameter 6”
Drive wheels diameter 14”
Complies with EN 12184 - 2008 / ISO 7176-19
Drive MWD
Seating system Matrixx
Controls VR2 / R-Net
Motor capacity 2 x 450 W
Crash test safe Yes
Hood colour Red / Silver
Back adjustment Manual / Electric
Seat angle adjustment Manual / Electric
Seat lift Manual / Electric
Leg rest adjustment Manual / Electric
afmetingen
Characteristics

The Morgan in brief

Customised seat support

  • Individual seat support thanks to the Matrixx seating system
  • Adjustable seat angle, back angle and seat heigh

Customised controls

  • Individual control options

At home & in the office

  • High seat elevation means you always have the right seat height
  • OMNI control option, can be extended with Bluetooth module

Comfortable and safe on the road

  • Independent suspension
  • Holds its course thanks to built-in gyroscope
  • Small turning radius
  • Midwheel drive provides intuitive manoeuvrability
  • Comfort on any terrain thanks to independent wheel suspension system

Stability and safety guaranteed

  • CE conformity marking and crash test-safe combination

Easy to maintain and reusable

  • Reliable, proven quality
  • Open system for easily adding on electronic components
  • Very reusable thanks to individually adjustable seat frame and the Matrixx seating system

Unity of frame and Matrixx seat support

  • Matrixx seating system fitted in black retaining all Midnight blue specifications
